Series SIOV-S07K
- Pitch 5.0 mm
| Specification: | |
|---|---|
| Tolerance: | ± 10% |
| Temperature range: | -40°C up to +85°C |
| Operate time: | < 25 ns |
| Withstand voltage: | ≥ 2.5 kV |
| Insulation resistance: | ≥ 10 MΩ |
| Specification: | ≤ 68 V: | > 68 V: |
|---|---|---|
| Rated power: | 20 mW | 250 mW |
| Max. Surge current: | 250 A | 1200 A |
| Packing unit: | 1000 pcs | |
| Dimensions (mm) | ||
| b: | ≤ 9.0 | |
| l: | ≥ 25.0 | |
| d: | 0.6 ± 0.05 | |
| e: | 5.0 ± 1.0 |
| Item: | Varistor Voltage: | Max. Voltage: | a (± 1): | s (max): | h (max): |
|---|---|---|---|---|---|
| SIOVS07K30 | 47 V | 30 Vac / 38 Vdc | 1.5 | 3.7 | 11.0 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | EPCOS |
