Further pin numbers up to 8 pin are available on demand!
| Specification: | |
|---|---|
| Voltage rating VDE: | 250 V |
| Current rating VDE: | 16 A |
| Rated cross section | |
| Single wire (solid): | 1.5 mm² |
| Stranded wire (flexible): | 0.2 mm² |
| stranded with ferrule: | 1.0 mm² |
| Stripped length: | 10.0 mm |
| Terminal block: | Stainless steel |
| Soldering tag: | Brass |
| Insulator: | PA 6.6 |
| Temperature range: | -30°C / +105°C |
| Inflammability class: | UL 94 V-0 |
| Soldering temperature: | 265°C |
| Peak soldering time: | 3-4 s |
| Colour: | basalt grey |
| Item: | Description: | Factory number: |
|---|---|---|
| AKZ43012KD | 2 pin with screw blade lever | AKZ 4301 / 2 KD 5.08 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | PTR A Phoenix Mecano Company |
