Weitere Polzahlen bis 12 pol. sind auf Anfrage lieferbar!
| Specification: | |
|---|---|
| Voltage rating VDE: | 250 V |
| Current rating VDE: | 3 A |
| Rated cross section | |
| Single wire (solid): | 1.5 mm² |
| stranded: | 1.0 mm² |
| stranded with ferrule: | 0.5 mm² |
| Stripped length: | 9.0 mm |
| PCB Hole Ø: | 1.0 |
| Soldering tag: | Cu |
| Insulator: | PA 6.6 |
| Temperature range: | -30°C / +105°C |
| Soldering temperature: | 265°C |
| Peak soldering time: | 3-4 s |
| Inflammability class: | UL 94 V-0 |
| Colour: | slade grey |
| Item: | Description: | Factory number: |
|---|---|---|
| AK42912KDVP | 2 pin with screw lever and with alternating pins | AK 4291 / 2 KD VP 3.5 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | PTR A Phoenix Mecano Company |
