Further pin numbers up to 24 pin are available on demand!
| Specification: | |
|---|---|
| Voltage rating VDE: | 150 V |
| Current rating VDE: | 9 A |
| Rated cross section | |
| Single wire (solid): | 0.75 mm² |
| Stranded wire (flexible): | 0.75 mm² |
| Stranded with ferrule: | 0.34 mm² |
| Stripped length: | 4.0 mm |
| Terminal screw: | M 1.6 |
| Allowed torque: | 0.1 Nm |
| Terminal block: | Brass |
| Solderung tag: | Brass |
| Temperature range: | -30°C / +105°C |
| Soldering temperature: | 265°C |
| Peak soldering time: | 3-4 s |
| Inflammability class: | UL 94 V-0 |
| Colour: | green |
| Item: | Description: | Factory number: |
|---|---|---|
| AKZ6922V | 2 pin vertical | AKZ 692 / 2 2.54 V |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | PTR A Phoenix Mecano Company |
