Részletek
Further pin numbers up to 16 pin are available on demand!
| Specification: | |
|---|---|
| Voltage rating VDE: | 400 V |
| Current rating VDE: | 12 A |
| Rated cross section | |
| Single wire (solid): | 4.0 mm² |
| Stranded wire (flexible): | 4.0 mm² |
| stranded with ferrule: | 2.5 mm² |
| Stripped length: | 7.0 mm |
| Screw size: | M3 |
| Allowed torque: | 0.5 Nm |
| Terminal block: | Brass |
| Contact spring: | Bronze |
| Insulator: | PA |
| Temperature range: | -30°C / +105°C |
| Inflammability class: | UL 94 V-0 |
| Colour: | green |
| Item: | No. of contacts: | Factory number: |
|---|---|---|
| AKZ9654F762 | 4 pin with flange | AK Z965 / 4 F 7.62 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | PTR A Phoenix Mecano Company |
