Részletek
| Specification: | |
|---|---|
| Contacts | |
| Contact arrangement: | 1 double throw |
| Contact direction: | straight |
| max. Switching voltage: | 125 Vac / 60 Vdc |
| max. Switching current: | 1 A |
| max. Switching capacity: | 62.5 VA / 30 W |
| Material: | silver, gold plated |
| Reel | |
| Nominal Power: | 150 mW |
| General information | |
| Must operate voltage / | |
| Must release voltage: | |
| 5 Vdc: | 4.0 V / 0.5 V |
| 12 Vdc: | 9.6 V / 1.2 V |
| 24 Vdc: | 19.2 V / 2.4 V |
| Operate time: | 5 ms |
| Release time: | 5 ms |
| Withstand voltage: | 1000 Vac for 1 min. |
| Temperature range: | -40°C up to +70°C |
| Approvals: | UL, CSA, RU |
| Dimensions: | 12.5 x 7.5 x 10.0 mm |
| Item: | Nominal | max. operating | Voltage rating: | Coil resistance: |
|---|---|---|---|---|
| voltage: | voltage: | |||
| G5V112DC | 12 Vdc | 24 V | 12.5 mA | 960 W |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | OMRON |
