PLuft = airflow, ± 10 %
Pel= power consumption, ± 15%
This item LA1225 is discontinued!
| Specification: | |
|---|---|
| Termination: | Strands AWG28, stripped, tin plated |
| Withstand voltage | |
| at 65% r.F.: | 500 V AC for 1 min. |
| Insulation resistance | |
| at 500 V DC: | > 500 MΩ |
| Insulation class (100 °C) | |
| LA1225: | E |
| MC25101V2A99: | A |
| Storage temperature: | -40 ... +70°C |
| Operating temperature: | -10 ... +70°C |
| Dimensions (mm): |
| Item: | Bearing: | Voltage: | PLuft: | Noise: | I: | Pel: | Speed: |
|---|---|---|---|---|---|---|---|
| MC25101V2A99 | Vapo | 4.5 ... 13.8 V DC | 3.0 m3/h | 16.0 dBA | 0.0378 A | 0.45 W | 10000 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | SUNON |
