certified according to EN 50262
The integrated sealing lip replaces the connecting thread´s washer!
Please order fitting counter nuts separately!
| Specification: | |
|---|---|
| Material: | polyamide |
| Protection class: | IP 66 according to EN 60529, |
| IP 68 up to 5 bar according to EN 60259 | |
| Thermal resistance: | continuous -25°C up to max. +80°C, |
| temporary up to +120°C | |
| Flame protection: | +750°C, filament test according to |
| DIN VDE 0471 part 2 | |
| Gasket: | EPDM |
| Dimensions (mm) |
| Item: | Colour: | AG: | H: | GL: | SW: | Ø - Ø: |
|---|---|---|---|---|---|---|
| KVS2GR | grey | M16 x 1.5 | 22 | 9 | 20 | 4 - 10 |
