The ERNI Power Tap is designed to bring power to printed circuit board applications. It allows for wire-to-board connections with common terminals. The 6 pin version has three solder pins per row with a two-row PCB layout.
The operating current is determined by characteristics of the PCB and the cable termination. This power supply cable can be connected with a screw mount terminal accomodating M3, M4, 6-32UNC or 8-32UNC screws.
The operating current is determined by characteristics of the PCB and the cable termination. This power supply cable can be connected with a screw mount terminal accomodating M3, M4, 6-32UNC or 8-32UNC screws.
| Specification: | |
|---|---|
| Max. hand soldering temperature: | 3.5 s at 350°C |
| Max. dip soldering temperature: | 10.0 s at 260°C |
| Contact: | Cu alloy |
| Surface: | Sn |
| Ampacity: | 40.0 A (20°C) |
| Dimensions (mm) |
| Item: | Version: | Screw mount terminal: |
|---|---|---|
| E214782 | 10 pin pressfit | M4 |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | ERNI Electronics |
