Részletek
Receptacles for 3½ power plugs with PCB contacts.
| SPECIFATION: | |
|---|---|
| Current rating: | 3 A |
| Voltage rating: | 250 V |
| Insulation resistance: | 1000 MΩ min. |
| Contact resistance: | 20 mΩ max. |
| Dielectric voltage: | 800 V AC |
| Operation temperature: | -25 °C to +85 °C |
| MATERIAL: | |
| Housing: | Nylon 66 white UL94V-0 |
| Contacts: | Brass |
| FINISH: | |
| Contacts: | Tin plated |
| HANDLING: | |
| Packing: | Bulk |
| TOLERANCE: | |
| .X | ± 0.30 |
| .XX | ± 0.20 |
| Item: | Description: |
|---|---|
| FK03PN | straight |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | econ connect |
