Részletek
- universal input
- protections: short circuit/over load/over voltage
- overload protection, current limiting, auto recovery
- built-in active PFC function
- suitable for LED lighting and moving sign applications
- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
- IP65, for indoor and outdoor installations
- adjustable output voltage with internal potentiometer
- adjustable output current with internal potentiometer
Detailed datasheets are available on request!
| Specification: | |
|---|---|
| Input voltage: | 90 up to 305 V AC |
| 127 up to 431 V DC | |
| In-rush current: | max. 75 A |
| Overload protection: | 95% up to 108% |
| Withstand voltage: | |
| I/P - O/P: | 3750 V AC |
| I/P - FG: | 1880 V AC |
| O/P - FG: | 500 V AC |
| Operating temperature: | -40°C up to +70°C |
| Dimensions (LxWxH): | 244.2 x 68 x 38.8 mm |
| Weight: | 1300 g |
| Item: | Output voltage.: | Rated power: | Tolerance: | Ripple: | Current: |
|---|---|---|---|---|---|
| HLG240H-24A | 24 Vdc | 240 W | ± 1.0% | 150 mV | 0A - 10.0 A |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | MEAN WELL |
