These sets allow for controlling a computer or KVM switch by two keyboards, monitors and mouses, one of each is local and one is connected to the remote module. All data is transferred between the local and the remote module by just one single economic Cat.5 cable - at a distance of up to 150 m.
- Enables connection of another computer to the remote module
- Enhanced transmission distance of up to 300 m
| Terminal Consoles: | |
| Keyboard: | 6 pin mini-DIN Jack (purple) |
| Mouse: | 6 pin mini-DIN Jack (green) |
| Video: | 15 pin DSUB-HD Jack (blue) |
| |
| Terminal PC: | |
| Keyboard / Mouse / Video: | 15 pin DSUB-HD Jack (yellow) |
| |
| other Terminals: | |
| Connection: | 8P8C Modular Jack |
| Power supply: | DC-socket |
| |
| max. Resolution: | 1600 x 1200 (bis 150 m) |
| 1024 x 768 (bis 300 m) |
| max. Cable length: | 300 m |
| Housing: | metal |
| Dimensions: | 139 x 81 x 34 mm |
| Weight: | 400 g |
| CE252LR | Set, consisting of local and remote module | PS/2 |
