Pitch 1.27 mm
Colour sequence: brown, red, orange, yellow, green, blue, violet, grey, white, black
minimum order quantity: 1 PU = 30.5 m (100 ft) ring
| Specification: | |
|---|---|
| Operating voltage: | 300 V eff |
| Dielectric voltage: | 2000 V eff |
| Ampacity: | 1 A |
| Capacitance: | 45 pF / m |
| Conductor resistance: | 230 Ω / km |
| impedance: | 104 Ω |
| Crosstalk: | 60 dB (asymmetrical) |
| 50 dB (symmetrical) | |
| Temperature range: | -30°C up to +105°C |
| UL style: | 20029 |
| Item: | No. of contacts: |
|---|---|
| AWG28/10F | 10 |
