Intelligent graphics displays with various graphics operations and fonts.
- TFT graphics display with various graphics functions
- white LED illumination, adjustable by software
- rotated mounting possible, orientation switchable by software
- eight pre-defined fonts, individually customizable
- every font is scalable from 2 mm up to 80 mm and may be rotated by 90° steps
- 3 different interfaces: RS232, I²C, SPI
- eight digital inputs and eight digital outputs
- two analogue inputs, comfortably programmable
- also available with analogue touchpanel with variable pitch
| Item: | Resolution: | Dimensions: | Colour: | Touchpanel: | EA item: |
|---|---|---|---|---|---|
| DIPTFT70ATP | 800 x 480 Px | 170 x 112 mm | 16 bits Color | analogue | eDIPTFT70-ATP |
További információk
| Minimálisan rendelhető mennyiség | 1.0000 |
|---|---|
| Gyártó | ELECTRONIC ASSEMBLY |
